YT-LII Automatic Paper Bowl Forming Machine is developed on the base of absorbing the advanced technology from home and abroad.It is an automatic multi-working-station machine with photosensor detecting,failure alarming and counting function. It this machine,adopt ultrasonic system to seal the cup-side body,so it available for making big size paper bowl both one -side and two-side PE,such as soup bowl, fast noodle bowl tec.The procedure as following:Automatic paper feeding,sealing silicon-oil lubricating,bottom punching,two-step bottom heating,knurling,curling and bowl discharging.
Technical Specification：
|
Model
|
YT-LII
|
|
Cup size
|
20-60oz
|
|
raw materials
|
Tow-sides/One-side PE(polyethylene)
film coated paper(180-4200g/m²)
|
|
productivity
|
30-40 pcs/min
|
|
Power Supply
|
380V 50Hz/380V 50Hz
or other required
|
|
total power
|
8kw
|
|
weight
|
2300KG
|
|
The size (length * width * height)
|
2960×1300×1820mm
|
